The primary purpose of CAD floor plans is to ensure that the construction of a building runs as planned, given the drawing specifications provided. If homeowners are trying to obtain financing for their house, banks (or other financial institutions) may require blueprints to be included in the proposal. Since the property will be used as collateral for the loan, the bank needs to know how much the property is worth. The blueprint provides a glimpse of the house design, size, materials, and all the particulars to help with the underwriting process.
Blueprints are technical drawings to be used as references for engineering design services and the construction of new buildings and renovation projects. They are drawn by professionals such as draftspersons or architectural drafters, who may offer their services through architectural design firms or on a freelance basis. The cost to hire a professional drafter ranges between $800 and $2,700, depending on complexity, or an average of $1,750. A draftsperson’s hourly rate will range from $50 to $130. It takes at least ten hours to draw the blueprints of a three-bedroom house and costs anywhere from $500 to $2,000.
RELATED: How much do CAD drawing services cost for design drafting & architectural blueprints?
Although “blueprints” and “floor plans” are sometimes interchangeable, they can mean two different things. “Blueprint” refers to a technical drawing used as a construction document or a guide for builders. The term is derived from the old-fashioned printing method, which uses white lines on blue paper. Floor plans, either 2D or 3D, provide a bird’s eye view of the room layout of a house. 2D CAD floor plans are often visually rudimentary, showcasing only the layout and specifications (such as sizes of the rooms and doors or windows placements) but with minimum detailing on walls and interiors.
A 3D floor plan rendering company drafts a 3D floor plan is a construction mockup with a high level of detail on the interior, including furniture, decorations, fixtures, and a photorealistic view of floor type and color. Blueprint (the printing method) is now considered obsolete and has been replaced by conventional whiteprint. As such, the term is now used, even by professionals, to refer to floor plans or other architectural drawings.
RELATED: The power of architectural CAD services
Home and interior designers tend to rely on floor plan software to draw the layout of a house during the project’s initial phase. The software allows them to create a simple view of the interior from a bird’s eye perspective with information about room specifications. The 2D process is quick and straightforward, albeit not visually appealing.
A 3D floor plan software program gives a detailed appearance of the layout. To create a finished interior look, 3D architectural modeling designers can insert 3D models in the image, such as furniture pieces and decorations. Walls and windows are presented in photorealistic views as well. Designers use the 3D renderings of a floor plan primarily for presentation purposes.
RELATED: 3D house and floor plan rates & costs for drafting services companies
Designers will use CAD software to create more technical and sophisticated drawings. An architectural plan drawn using CAD software may include detailed annotations for documentation and information required by architects, engineers, and contractors involved in the project. Such software is not user-friendly, and the resulting image can be very complex.
Most homeowners do not need a blueprint for anything apart from financing their house. The technical drawings and all the information they contain are meant for the professionals working on the project. However, a blueprint is essential for documentation. A homeowner may refer to the blueprint for future remodeling or renovation. Having a reliable reference for the existing building prevents the homeowner from making mistakes when making structural alterations.
RELATED: How much do architectural design services cost for freelance design service firms?
Qualification | Hourly Rate |
Licensed Architect | $100 – $350 |
Certified Drafter | $80 – $150 |
Freelance Drafter | $35 – $150 |
The cost of hiring 3D Floor plan design services to draw a detailed architectural floor plan is affected by project size, complexity, timeframe, plan specifications, and location. Professionals in big cities may charge a higher rate than their suburban or rural counterparts.
RELATED: Drafting services rates vs. architectural development costs & differences in pricing
The architect is among the most highly qualified professionals in construction-related affairs. Individuals must complete a four-year college degree to become licensed architects, undergo years of professional training, and pass a demanding series of exams (at least in the United States and Canada). Some architects refer to themselves as designers because only licensed can claim the Architect title. They are professionally trained and have the expertise to perform engineering, design, and drafting works. A licensed architect is a safe bet if you want an adequately drawn floor plan. An architect’s hourly rate ranges from $100-350 per hour.
Professionals who can draw floor plans for a fee include draftspersons and designers. They may work in an architectural firm under the supervision of engineers or licensed architects or as independent freelancers. When working with professionals of this category, it is essential to check their portfolios and references from previous clients. The rate for a certified drafter ranges from $80-150 per hour.
RELATED: Billable rates for architect’s design services, architectural costs & hourly fees
The nature of freelancing allows anyone to offer any service with few restrictions on qualifications or academic experiences. To avoid hiring the wrong person, choose an architectural drafting service with a good track record verifiable by client’s reviews. The hourly rate varies widely between $35 and $150, depending on location and reputation, and some freelancers charge by the project.
The rate per square foot will vary according to the plan’s requirements and the project’s complexity. The cost ranges from $0.50 to $3 per sq. ft. If you hire a licensed architect, the rate runs from $1.25 to as high as $10. In other words, the floor plan for a 1,000 sq. ft. house costs between $500 to $10,000.
RELATED: What are architectural animation costs, rates, & 3D design pricing for companies?
The cost above is based on the architectural drawing services provided, i.e., drawing the floor plan. Architects, engineers, and contractors refer to the plan when communicating ideas, developing an action plan, or making suggestions for changes. When the project concludes, all alterations will be noted. Since the plans are drawn using computer software (floorplan-specific or CAD for easy alteration during the project), the original images are digital files. An hourly rate may already cover the fee for printing hard copies; if it doesn’t, it is a reasonably affordable cost.
A physical copy of a blueprint costs between $0.06 to $25 per sheet, and one hard copy of the blueprint may be included as part of the hourly drafting rate. An average house needs ten sheets per level, but you may not need that many to draw the floor plan. Digital PDFs or other image file formats should be sufficient, as they can be displayed and viewed comfortably on a tablet or laptop. However, hard copies are still in demand for various purposes, such as documentation of a completed project or communicating ideas with clients.
RELATED: How much does an architect or architectural firm cost for home design?
Contractors may request a copy to study and help them understand the concept of architectural planning and design services. Depending on size, there might be an additional cost for waterproofing, ranging from around $3 to $20 per sheet. The most common paper size for a blueprint is 24″ by 36″, also known as an architectural “D” drawing, although larger sizes up to 36″ by 48″ are available.
A blueprint is essentially a manual for construction. Once the homeowner approves and the draftsperson signs, the planning phase concludes. That said, homeowners can always propose changes to the original design. Revisions can be expensive, ranging from $400 for a simple alteration to $2,500 for a significant modification. Consult a professional before finalizing a floor plan to avoid the extra cost.
RELATED: Learn about architectural design fee schedules, rates, and pricing for architect firms’ costs
The level of education is one of the most significant differences between a licensed architect and a draftsperson. An architect requires several more years of study and extensive field internships. While both can draw a detailed floor plan, a draftsperson is only responsible for the drawing, while an architect can provide engineering oversight. In most residential design cases, a drafter can draw a complete set of floor plans without help from an architect or any more qualified professional. If you have to hire a drafter, opt for a proven track record and reputable credentials, such as ADDA (American Design Drafting Association) certification.
A drafter takes your ideas for a house design and transforms those concepts into a workable plan for the construction process. The job is done once the blueprint gets approval from the homeowner and the drafter’s involvement in the project ends there. From a house design perspective, drawing a blueprint is not the job’s most technical or consequential part. A licensed architect can make blueprint modifications during construction to improve safety, management, efficiency, and eco-friendliness. An architect may supervise, oversee, verify, and manage an entire project until completion, depending on the agreement made.
RELATED: Why hire an architectural design service?
An architect is the best way to go if you want engineering know-how, design expertise, and technical drawings. However, there might be some cases when a homeowner only wants a 3D floor plan for interior design purposes with minimum engineering input. A draftsperson can effectively draw the blueprint if the main objective is to create a guideline for builders to follow.
Both a licensed architect and certified drafter are qualified for the job. Check with your local building authority to see if a project requires an architect’s oversight. Sometimes it only means that you need an architect or design engineering professional to draw and sign the blueprint, especially for new construction. An architect is not required for most remodeling projects.
If you purchase a house but don’t receive the floor plan or the complete set of blueprints, it does not mean the document does not exist. There are a few places where you can ask for a copy. The first option is the realtor who sells you the house. Some realtors don’t keep a copy, but they have the resources to help you obtain the record, for example, the company—architectural or construction firm—that built the house in the first place. Another option is the municipality responsible for issuing the building permits.
RELATED: 7 Professional CAD drawings by Cad Crowd’s best freelancers
RELATED: Tips for hiring and managing freelance CAD design and 3D modeling pros
Upon project completion, the contractor should draw a final plan to show changes made to the original blueprint during construction. Also known as “red-line drawings,” they are produced by contractors, not architects or draftspersons, for liability reasons.
