This article is a comprehensive guide to SLS 3D printing services for companies, With a whopping value of $13.84 billion, the additive manufacturing industry is one of this modern era’s fastest-growing manufacturing technologies. SLS, or Selective Laser Sintering, is among the breakthrough 3D printing technologies that catapulted its quick rise to popularity and paved the way to wide-scale adaptation across various industries.
SLS 3D printing firms use a source of heat energy in the form of a guided laser to sinter layers of raw material particles into a durable and robust build. Once heated, these particles don’t melt as they merge. It is known as a sintering instead of a melting process. SLS 3D printers also come in various build volumes that range from large-scale industrial to desktop.
RELATED: What is 3D printing? A beginner’s guide
They also differ in manufacturing accuracy, cost, laser power, and laser type, which can be CO2 lasers, diodes, fiber, or others. The technique is famous for its viability for rapid prototyping and manufacturing functional parts. The sought-after material qualities of SLS 3D printer parts are promising factors for both product developers and manufacturers.
Several steps are involved in SLS 3D printing, and these are the following:
Everything begins with the CAD model of the specific part that will be printed. The final model will then be transferred to the built-in user interface of SLS printers or the slicing software in the file formats that suit 3D printing. STL is the most popular file format used these days. The slicing software will then get the CAD file ready for 3D printing services. It generates commands called G-Codes that the controller of the printer can interpret in terms of the laser’s scanning motion. The software also integrates user-defined settings like resolution, laser power, and layer thickness that serve as the defining factors for the quality of the final build.
This is also the stage where the software forecasts critical data like material consumption and print time.
RELATED: 3D Printing technologies for modeling and prototyping
The SLS 3D printers are complex machines needing care and training. Before the actual printing process starts, several checks are conducted to guarantee the smooth flow of printing. The powder bed or build chamber is filled to the right level and with the suitable material. Aside from this, professional operators also conduct several preprint CAD checks to ensure any loopholes won’t compromise printability.
There is also the need to calibrate the galvanometers or the mirrors directing the laser beam along the preferred printing path. The servomotors that set them in motion are brought to their home positions for minimal errors. Manufacturing design professionals usually recommend the schedules for calibration for these in handbooks.
RELATED: Additive manufacturing materials: 3D printing in 2018
The build chamber’s powder content is preheated before the start of the printing to just under its melting point. Through this, the laser’s heat energy is just used in sintering. It then makes way for speedy 3D printing.
The printing process itself is ingenious and simple. The laser will scan the upper layer of the part that the slicer defined above the powder bed’s top surface. The laser power is set accurately to attain a sintering depth equivalent to layer thickness. The standard layer thickness range is 0.05 to 0.15mm in SLS 3D printing. The bed then moves down by a thickness of a single layer and takes the build with it. A new, fresh layer of SLS material spreads throughout the bed by recoating the roller or blade. The laser will then scale the second layer by joining the first one. The process continues to repeat until the completion of printing the whole part.
RELATED: 6 Ways 3D printing will change the world
Once the print has been completed, it is given time to cool down first for some time within the chamber. After it cools down, it will be removed from the build chamber. Since un-sintered powder surrounds all sides of the part, the extraction process is usually called depowering.
SLS 3D printing offers a long list of benefits, which makes it among the most in-demand design for additive manufacturing services in industrial applications.
3D printers are available in various build chamber volumes with a maximum of 750mm in a single direction for larger machines. The productive approach is to take advantage of the build chamber volume through batch printing. It means fitting as many parts possible as a batch within the chamber. It is prudent because the laser scanning process is rapid and easy. A single scan in batch printing can sinter layers of several parts instead of a single one to help save hours in printing time.
RELATED: 3D Printed threads and screws: innovative product design options for companies
SLS can produce highly accurate parts. As stated earlier, the layer height can go as low as 0.05mm. Many 3D printers also can manufacture tolerances within a range of more or less 3%. The powder bed’s packing pressure also helps minimize warpage. This is the reason why SLS 3D printed parts are already near-net shape without the need for extensive post-processing.
3D-printed structures with features such as bridges or overhangs need supporting geometry to uphold the elements throughout the printing process. Many 3D printing methods, for example fused deposition modeling, waste a lot of material and time printing the supporting structures. However, it’s not an issue regarding selective laser sintering. Since a pool of loose powder entraps the entire build, it already has sufficient support throughout the body. It not only helps save time, but it also reduces costs.
RELATED: How 3D printing can revolutionize plastics recycling
SLS machines are known as speedy 3D printers whose commercial printing speeds can reach as fast as 48 mm/hr. It beats many other alternative methods of 3D printing out there. Aside from this, the process’s workflow is also time-efficient despite being divided into several steps. Laser scanning is also almost instantaneous, with the build chamber able to detach and replace with a different one while the first is cooling down. Batch printing is also possible.
The SLS 3AD printed parts created by skilled manufacturing design professionals offer beneficial properties of air and water-tightness, heat resistance, tensile modulus, and mechanical strength. It is because of the sintering process that strongly bonds the individual polymer particles together. This robust quality is why SLS printers are a standard piece of equipment used to develop and test functional prototypes that mimic the appearance of the test product and its functionality.
RELATED: 3D Printing with metals: making fully metal parts and products with additive manufacturing
Just like other manufacturing processes, SLS could be better, as it also has its own set of disadvantages. Here are some of the top things you need to consider before you opt for SLS:
In general, SLS printers are expensive machines. You can expect to spend as much as $5,000 on the cheaper versions, while high-end versions can go as high as $100,000, or more. However, cheaper printing and material costs somewhat offset the initial investment. A new wave of state-of-the-art benchtop 3D printers is joining the market that isn’t as pricey but still offers decent specifications.
RELATED: Guide to surface finishing for 3D printed parts
Despite the accurate dimensions, the final build has no shiny, smooth surface. It might even need additional surface treatments to meet the manufacturing requirements most of the time. Competing methods, such as Stereolithography, have a relatively better surface finish.
SLS material is available as fine powders with particle sizes as tiny as 20 microns. The particles with such small dimensions can quickly enter the respiratory system and cause health problems. Sintering can produce fumes that might escape the work environment, causing negative environmental contributions. It’s recommended that operators use suitable PPEs, such as gloves and masks when dealing with or handling such materials.
RELATED: Selecting materials for 3D printing your new product or prototype
Selective laser sintering doesn’t provide a solid and extensive catalog of materials. Aside from several types of thermoplastic elastomers, Thermoplastic Polyurethane or TPU, and nylon, materials compatible with SLS may be challenging. Physical appearance is limited to metallic greyish finishes as well. Although scientific research is growing SLS printing’s scope of materials further, it currently needs to be improved.
Selective laser sintering has undoubtedly made a significant mark on the additive manufacturing landscape in the past few years. Its utilization and potential are continuously growing as it also constantly catches the interest of many industrialists.
If you’re looking for experts in SLS 3D printing, Cad Crowd is the favorite go-to platform where you can find professionals to help you with your projects. Contact us for a free quote.
